Comelit 4893M - Actuator Control via Entrance Panel Relay; Using the Entrance Panel Relay for Actuator Control

46
Using the entrance panel relay on generic actuator control
1209
ON
1 2 3 4 6 75 8
4A MAX
AC-DC
12V/24V
4893M
LL
O
D
E
T
R
NO
SE
-
SE
+
NC C
M
O
C
“C.NC.NO relay activation time: 2 sec.” (default)
f Set DIP switch 1 to ON permanently (as shown in the figure, see Entrance panel settings on page 12).
