3
1
6
4
12 V~
230 V~
1.
2.
4
Transformer art. 1200 with 230V primary, 12V AC / 15 VA secondary winding for continuous use.
Dimensions: 53x95x65 mm (3 DIN modules).
1. 230 V digital input
2. Secondary 12 V AC output
Disconnect the power supply before carrying out any maintenance procedures.
The electrical system of the building must be fitted with an omnipolar mains switch with a contact opening of
at least 3 mm, which is capable of isolating the power supply of the device.
Place the protection back over the terminals and close the inspection door after every procedure.
Transformer
Description
