Comelit simple key - TCP;IP Network

RS 485*
D+ D-
12 - 24 Vca
12 - 33 Vcc
12 - 24 Vca
12 - 33 Vcc
12 - 24 Vca
12 - 33 Vcc
IT
EN
FR
NL
ES
12 - 24 Vca
12 - 33 Vcc
12 - 24 Vca
12 - 33 Vcc
12 - 24 Vca
12 - 33 Vcc
IT
EN
FR
NL
ES
IT
EN
FR
NL
ES
15
Rete RS485
Rete TCP/IP
*CavoRS485–impedenza120Ohm,capacitàconsigliatainferiore
a 50 pF/m: Cavo BELDEN rif. "BLN 9841T2" o "BLN 9841T3" o
equivalente
RS485 network
TCP/IP network
*RS485cable-120Ohmsimpedence,capacitylessthan50pF/m
suggested:BELDENcableref."BLN9841T2"or"BLN9841T3"or
equivalent
Réseau RS485
Réseau TCP/IP
* Câble RS485 - Impédance 120 ohms, capacité inférieure à 50
pF/msuggéré:CâbleBELDENréf."BLN9841T2"ou"BLN9841T3"
ou équivalent
Netwerk RS485
Netwerk TCP/IP
*kabelRS485-impedantie120Ohm,capaciteitminderdan50pF/m
aanbevolen:BELDENkabelref."BLN9841T2"of"BLN9841T3"of
gelijkwaardig
Red RS485
Red TCP/IP
* Cable RS485 - 120 Ohms de impedancia, capacidad inferior a
50pF/m,recomendado:CableBELDENref."BLN9841T2"o"BLN
9841T3"oequivalente
