• Take the high pressure cleaner to the place of work using the handle(4).
• Engage the parking brake(41) (FDX ENDURANCE).
• Unwind the high pressure hose completely(30).
• Connect a gardening type quickt coupling (FDX BLADE XL) to the water inlet hose-end tting(11)
or, exploiting the clamp(12) supplied, x a supply hose with an inside diameter of 19mm/0,75in.
OperationG in Fig.7.
• Start the engine, referring to the relevant operating and maintenance manual.
• Open the water supply tap (if connected to the drinking water mains it is mandatory to use a back-ow
preventer: to use this device refer to the relevant instruction manual), making sure there are no drips.
Alternatively, put a suction hose in a tank.
• Press the spray gun lever(33) and wait for a continuous jet of water to come through which means
the pump is priming correctly.
• Stop the engine, referring to the relevant operating and maintenance manual, and close the water
supply tap, if any.
• Press the spray gun lever(33) to discharge all residual pressure.
• Connect the lance hose(21) to the spray gun (19) depending on the type of high pressure cleaner you
have. OperationH in Fig.7.
STANDARD OPERATION HIGH PRESSURE
• Ensure that the nozzle holder head(24) is not in the detergent dispensing position (see also the
“operation with detergent” paragraph).
• Start the engine, referring to the relevant operating and maintenance manual.
• Open the water supply tap, if any.
• Press the spray gun lever(33) checking that the nozzle spray is uniform and there are no drips.
• If necessary regulate the pressure by way of the pressure regulating knob(17). Turn it clockwise to
increase pressure, anticlockwise to reduce it. You can see the pressure on the pressure indicator(18).
CAUTION
• Before expecting maximum performance of the high pressure cleaner it is good practice to warm
the engine up for a couple of minutes.
OPERATION WITH DETERGENT
The recommended detergents are more than 90% biodegradable. On how to use the detergent please
refer to the instructions given on the detergent label.
FDX BLAD XL/PRO
• In the case of suctioning from the high power cleaner’s tank (25), remove the cap (26) and, being careful
not to spill any liquid (maximum capacity is 3.5 l/0.92 US gal), ll the tank with the solution wanted.
FDX ENDURANCE
• Put the hose(31) in the external tank which has already been prepared with detergent to the strength
required: in this case too, follow the indications given for the dosage on the detergent pack label.
• Turn the nozzle holder head(24) as schematized in Fig.7-a and then operate the spray gun lever (33)
and start dispensing detergent.
• Release the lever(33) and turn the nozzle holder head (24) as schematized in Fig.7-b to stop dispensing
detergent and return to high pressure operation.
STOPPING OPERATION
• When the spray gun lever(33) is released it stops the high pressure jet and the machine goes to the
bypass mode.
• Pressing the spray gun lever(33) again the high pressure jet starts again.
EN
