Comflex Ultimate Series - Technical Data, Incl. System Information

User Manual Careleda P/L M-03 WI-364rev0 Edited 26.02.2020 15 | P a g e
CAREFULLY READ AND UNDERSTAND INSTRUCTIONS BEFORE USING CHAIR
GENERAL TECHNICAL DATA
DESCRIPTION
MODEL
Please note: that your particular model may have some of
the features listed and not others, depending on the
configuration chosen. The list of technical specifications
below is not exhaustive and if you require any further
information, please contact the company that sold the chair
to you.
CRN (Narrow)
CRS (Standard)
Armrest Height - at hips (from seat cushion)
160
160
Backrest - Height (from seat cushion)
700
700
Backrest - Recline Range (SEAT = 0°)
95˚ - 180˚
95˚ - 180˚
Backrest - Width at Shoulders (between Lateral Supports)
500
550
Castors - DL & TB type (individual locking)
100
100
Overall - Height (Backrest upright / seat at approx. 5˚ )
1200
1200
Overall - Length (Supine Position) - Deluxe Leg Rest Type
(Footplate out)
1830
1880
Overall - Length (Supine Position) - Standard Leg Rest Type
1750
1800
Overall - Width
700
750
Seat - Depth
520
570
Seat - Height - @ 0° degrees
550
550
Seat - Height - tilted forward
540
540
Seat - Width (between arms)
500
550
Weight Capacity (SWL) - Maximum
180kg
180kg
ARTG Number
136977
136977
 Dimensions are nominal and are measured in mm without covers depressed
 Specifications are subject to change without notice
 E & OE
5. Technical Data, Incl. System Information
