① 3.5mm TRS Audio Output Port
② Power/Mono/Stereo/Safety Mode Switch Button:
Long press for On/O; Short press for mono/stereo/safety mode switch
③ LCD Display
④ Belt Clip
⑤ USB Charging/Monitoring Port:
Insert USB-C headphone to monitor or connect the receiver and the power bank/DC power to
charge; Connect the 3.5mm headphone to monitor and the power bank/DC power to charge
simultaneously via the 2 in 1 monitoring/charging cable
⑥ Volume Control/Pairing/Display Rotation Button:
Short press for volume adjustment of channel A; Long press for display rotation
⑦ Volume Control/Pairing/Display Rotation Button:
Short press for volume adjustment of channel B; Long press for display rotation
⑧ Charging Contact
It is recommended to use USB-C headphone without DAC chip for better monitoring
experience.
