Stereo
A
VOL 4
B
VOL 4
C
VOL 4
D
VOL 4
1. 3.5mm Analog Output
When used with a camera, connect it through the 3.5mm TRS-TRS audio
cable; When used with a mobile phone or computer, connect it through the
3.5mm TRS-TRRS audio cable and related OTG audio cable/adapter; to
monitor according to personal needs (please purchase the relevant audio
cable/adapter by yourself)
Mono/Stereo Mode
Receiver(RX):
In stereo mode, A/C channel is the left channel, B/D channel is
the right channel
11
