Command access MLRK1 - Electrified Exit Device Installation Example; Recommended Power Supplies

Ceiling Tile
Legend
Standard Placement
Module
GREEN
CHANNEL 1
LED
NORMALLY OPEN
DRY CONTACT FROM
ACCESS CONTROL
SYSTEM
NO VOLTAGE
LOCKING
HARDWARE
+
-
CAT
ELECTRIFIED EXIT DEVICE
Installation Example
Command Access Technologies | 22901 La Palma Ave, Yorba Linda, CA 92887 | Phone:(888) 622-2377
Recommended PoweR SuPPlieS:
All Command Access exit devices & field installable kits have been thoroughly cycle
tested with Command Access power supplies at our factory.
