KNIGHT2
10
Returning the light to the nested position
The KNIGHT2 is equipped with an Autopark function as a standard feature. The green
button on the control box initiates the Autopark sequence. Once initiated, the “Emergency
Stop” red button indicator is illuminated. Pressing the “Emergency Stop” button will cancel
the Autopark sequence.
Autopark Sequence
Press green button on the controller once. It does not need to be held in position. The
Autopark sequence begins:
1. “Emergency Stop” light is illuminated.
2. Lamps are extinguished.
3. Upper stage begins rotation to the center position.
4. Once upper stage is centered, rotation stops, lower stage begins retracting.
5. After lower stage has fully retracted, upper stage begins retracting. Upon upper stage
retracting fully, “Emergency Stop” light turns off.
Installation
The KNIGHT2 must be installed by a designated installation facility by qualified personnel
only. All safety precautions must be thoroughly understood before installation. Please
consult the factory for additional installation information assistance.
Installation Kit
Included with the KNIGHT2 is an installation kit. Verify that the kit contains the following
items:
(1) 50 feet of 2GA-2 Conductor power cable (1) 50 feet of 22GA-20 conductor cable
(1) Pre-wired HOLSTER BOX w/cover (1) Handheld Controller
(1) Small hardware parts bag with:
(4) mounting spacers (4) 5∕16-18 x 2 ½” bolts
(4) 5∕16-18 nylon lock nuts (8) 5∕16” flat washers
(4) large diameter flat washers (2) ¼-20 x 5∕8” Phillips flat head machine screws
(2) ¼” flat washers (2) ¼-20 nylon lock nuts
(4) ½” 90° sealing connector w/nut (1) 1” 90° sealing connector w/nut
