Model CDV-70MF
Transmission Method
Camera 4 wire (polarity), CCTV 2 wire (polarity)
Interphone 4 wire (polarity), Sensor 2 wires(non polarity)
Power Source 100V-240V~, 50/60Hz
Consumption
Stand-by : 3.5 W
Max : 15 W
Intercom system HANDS FREE type (Voice switch circuit)
Monitor
7s FULL TOUCH LCD
Video
subscription time
Individual door camera monitoring: 30 ±5sec
Call connection / Calling: 60 ±5sec
Wiring
Distance
UTP
CAT 5e.
Standard
(ø 0.5)
Camera / CCTV / Interphone <-> Household unit (monitor)
28 meters (MAX)
Resistance under 10Ω per 100 meters on UTP Cat 5e
Operating Temp.
0 ~ +40 (32°F ~ 104°F)
- Make sure to turn on the product.
- In case if physical damage or operation failure is detected, do not hesitate to
contact Service Center.
- All electric power must be blocked by the building blocking device.
- Do not place water bottles or flowerpots upon the product.
- Please, turn the power off when installing or repairing the product.
8.
Specifications
9.
Safe operation guide
