10. Specifications and Features
Rated Voltage 100-240V~, 50/60Hz
Power Consumption Operating : 10W
Wiring 4 wires with door camera (Polarity),
4 wires with an Interphone (Polarity)
Screen Size Color 4.3" TFT LCD
Communication Simultaneous communication
From a door camera : Electric chime
From an interphone : Beep sound
Time to display the screen 60 ± 10sec
Distance from camera 28m(Ф0.5) / 50m(Ф0.65) / 70m(Ф0.8)
Operating Temperature 0 ~ +40℃ (32°F ~ 104°F)
CMV-43A
Call Sound
Reference : Design and functions of the product are a subject of constant
development as a pursuit of quality improvement
11.
Safe Operation guide
●
Make sure to turn on the product
●
In case if physical damage or operation failure is detected, do not hesitate to
contact Service Center
●
All electric power must be blocked by the building blocking device
●
Do not place water bottles or flowerpots upon the product
●
Please, turn the power off when installing or repairing the product
