2
1. Overview
Controls and functions
Handset
LED Display
Call Buttons
Pick UP/ VOL
Hold / S.P
DIP Switch
2. System Features
2-1. Easy Wiring : Common 10(5p) conductor wiring. Easy to install
For offices, schools, factories, administration buildings, backs,
communication, the multiplexed, multi digital channel handset
warehouse, institutions and stores in the large capacity of
system provides convenient communication over 10 common wiring.
and saves in costs of installation.
2-2. Max 90 stations for versatile uses for officces, schools,
factories, etc.
2-3. Up to 3 independent Intercom channels available and possible
to transfer calls (Follow me function)
2-4. Absence indicator allows the caller to know that you are absent,
also rejects the incoming call.
2-5. Several stations can share same number.
2-6. Handfree call : Speaker button allows to call without holding
handset.
2-7. Group Division : All stations can be divided into four groups. 2
Group paging, Call transfer(Follow Me), and Call answer by
another station(Pick up) within a group are possible.
2-8. Caller Indicator Caller's station number displayed on LED of
the receiving station.
2-9. LED Display : The screen shows the status of the system in use.
FU is displayed when communication channels are full
PF is displayed when paging.
2-10. The system will let you know if the station you are calling is
engaged or is non-existent.
1. Overview ................................. 2
2. System Features...................... 2
3. Operation ................................ 3
4. How to arrange the self
address no .............................. 6
7. Installation .............................. 7
Contens
