Antenna Offset Left
Antenna Offset Right
1FT SHOWN FOR REFERENCE
Page 12 of 13
7708353
MOUNT ATTACHMENT AND ALIGNMENT
SECTION 5
INSTALLATION
INSTRUCTIONS
Pole to be structural engineer
approved rigid structural support
For installation of interface
see separate instructions.
Fit radio per instructions.
For installation of interface
see separate instructions.
Fit radio per instructions.
