About your AIS class B transceiver
Page 8
Figure 2 AIS transceiver overview
Electrical connections
The AIS transceiver has the following electrical connections:
• Power supply
• Two independent NMEA0183 data ports for connection to chart plotters and other NMEA0183 compatible equipment
• USB for connection to a PC or Mac
• External switch input for silent mode control
• NMEA2000 port for connection to NMEA2000 compatible equipment
