ComNav Class B AIS - 3 Installation; Preparing for Installation; Figure; Figure 4 Typical Installation Configuration

Installation
Page 10
3 Installation
3.1 Preparing for Installation
Figure 4 shows a typical installation configuration for the AIS transceiver. Please take the time to familiarise yourself with the system
elements and their connections prior to attempting installation.
Figure 4 Typical installation configuration
VHF antenna
GPS antenna
(optional)
Chartplotter
Power in
NMEA 2000
Switch
NMEA0183 device
USB
AIS Class B
transceiver
