WATER SHUTTERS
The water shutter is designed to keep the spraying
water from escaping the evaporator compartment.
To remove just the water shutters:
1. Grasp one end of the water shutter and lift up.
2. Pivot water shutter and disengage remaining
end.
3. To re-install into ice machine, grasp one end of
the water shutters, install one end, pivot the
opposite end and pull down into position. Make
sure tabs are secure in grooves.
To remove water shutter assembly:
1. Slide evaporator bucket forward 1/2” (13 mm).
2. Lift shutter assembly straight up.
WARNING
Removing the water shutters while the water pump is
running will allow water to spray from ice machine.
Disconnect the electrical power to the ice machine at
the electric service switch box and turn off the water
supply.
Grasp Water
