36
SPRAY BAR, WATER PUMP AND HOSE
Remove spray bar clamp and spray bar.
1. Grasp pump and pull straight down until water
pump disengages and electrical connector is
visible.
2. Disconnect the electrical connector.
3. Remove the water pump from ice machine.
4. Remove clamp from hose to remove from pump.
5. Do not submerse the water pump motor in
cleaner or sanitizer. If soaking is required,
immerse pump to normal water level during the
freeze.
WARNING
Disconnect the electric power to the ice machine at the
electric service switch box and turn off the water supply
before proceeding.
Remove
Clamp
Remove
Clamp
Maximum
Solution Height
When Soaking
DO NOT
Immerse Motor
in Solution
To Next Page
