CompAir L22 Service Manual

11. Annex
63
11.1.7 EUROPE version L132RS A - air-cooled W - water-cooled
Technical data 50 / 60Hz
L132RS
Maximum operating pressure
bar
13.0
Minimum operating pressure
bar
5.0
Ambient temperature
°C
1...45
at min. speed
at max. speed
7.5 bar
Flow
m
3
/ min
4.76
22.72
9 bar
Flow
m
3
/ min
4.72
21.18
10 bar
Flow
m
3
/ min
4.69
20.08
13 bar
Flow
m
3
/ min
5.73
17.26
After-cooler outlet temperature above ambient temp. (at full load)
°C
A - 8 / W - 9
Sound pressure level (to ISO 2151 at 70% load / at full load)
dB(A)
74 / 77
Nominal motor rating
kW
132
Voltage (frequency)
380V[+10%-5%];400V[+/-10%];460V[+/-10%]
(50, 60Hz)
Full-load current max. (380V / 400V / 460V)
A
297 / 283 / 246
Motor protection type
-
IP55, EFF1
Nominal speed
rpm
650...2980
A - kW
5.5 (50Hz) (IP54) ; 6.3 (60Hz) (IP54)
Nominal fan motor power
W - kW
0.37 (50Hz) (IP54) ; 0.66 (60Hz) (IP54)
Recommended cable cross-section at 75 °C (380V/400V/460V)
mm
2
3x150PE95 / 3x150PE95 / 3x150PE95
Recommended fuse size (380V/400V/460V), slow-blowing (type gG)
A
300 / 300 / 250
m
3
/ min
A - 273 (50Hz) ; 248 (60Hz)
Cooling air flow through ventilator
m
3
/ min
W - 100 (50Hz / 60Hz)
Cooling air outlet temperature above ambient temp.
°C
29 (50Hz) ; 30 (60Hz)
Max. allowable pressure drop in duct at ambient 35°C / 45°C
Pa
130 / 90 (50Hz) ; 70 / 40 (60Hz)
Cooling water quantity
l/min
170 @∆T = 12K @∆p = 2.1 bar
Cooling water inlet temperature
°C
min. 5 / max. 35
Cooling water outlet temperature
°C
55
Cooling water pressure
bar (g)
10
Cooling water connection
EN10226-1 Rp 1 1/4 (DIN 2999-R 1 1/4)
Total oil volume
l
54
Compressed air delivery connections (male screwed thread)
-
EN 10226 R 2 1/2 (DIN 2999-R 2 1/2)
Weight
kg
2786
Dimensions L x W x H
mm
2337 x 1368 x 2039
