CompAir V-Compact Series User Manual

CompAir Limited
page 34
3. MAINTENANCE PARTS (TWO YEARS OPERATION)
Items marked § refer to oil-free compressors only.
'A'
Oil Filter Element 1111
2nd stage Valve Plates 2244
2nd stage Valve Springs 6 6 12 12
1st stage Valve Springs 12 12 24 24
Diaphragms (unloader) 3366
Valve Joint Ring 6 6 12 12
Valve Lanterns 'O' Ring 6 6 12 12
Oil Filter Element 1111
'B'
Air Filter Element 1111
'C'
§1st stage Guide Ring 1122
§1st stage Pressure Ring 1122
§2nd stage Guide Ring 1122
§2nd stage Pressure Ring 2244
§Oil Wiper Ring 2244
§Oil Scraper Ring 2244
Seal 2244
'D'
1st stage Suction Valves 2244
1st stage Delivery Valves 2244
2nd stage Suction Valves 1122
2nd stage Delivery Valves 1122
Diaphragms (unloader) 3366
Main Bearing Bushes 2222
Oil Seals 2222
Big End Bearing, Half Liners 4488
Big End Bolts 4488
Small End Bushes 2244
Gudgeon Pins 2244
1st stage Piston Rings 2244
1st stage Conformable Rings 1122
2nd stage Piston Rings 2244
2nd stage Conformable Ring 1122
Shakeproof Washers 2244
Set of Gaskets and 'O' Seals 1111
Oil Pump Belt 1111
Service Description
Quantities required
V100 V150 V200 V300
