Chapter1 Introducing Your Notebook

- 20 -

1.3 Left Side

The following picture shows the left side of your netbook.

1 RJ-45

2 USB

3 Microphone Jack

4 Headphone Jack

5 Card Reader

1.3.1 LAN Jack

The RJ-45 network jack allows you to connect your netbook to a local area

network (LAN).

Be careful not to plug the telephone line into the slightly larger network connector.

1.3.2 USB Ports

Use this port to connect a USB device, such as a mouse, full-size external

keyboard, or printer, to the computer.

1.3.3 Audio Ports(MIC and Headphone)
