Compal PBL10 - System Setup Utility; Main Menu and Basic Settings

51
4.11 System Setup
4.11.1 Invoking setup
The setup function can be invoked by pressing F2 when “Press <F2> to enter
Setup” message is prompted on the bottom of screen during POST.
During setup, all Fn function keys and power saving functions are disabled.
4.11.2 Main Menu
InsydeH20 Setup Utility
Main Advanced Security Boot Exit
System Time [12:00:00]
System Date [01/01/2010]
Processor Type Type,XXXGHZ
System Memory Speed
XXXX MHz
Total Memory XXX MB
EC version
System BIOS
Version:
X.XX.XX
Intel ME Version
HDD Disk: XXXXXX
CD/DVD Rom: XXXXXX
Removable Device
State:
XXXXXX
Details see the following
Help Information
Serial Number
UUID
F1 Help ↓↑Select Item F5/F6 Change Values F9 Setup Defaults
Esc Exit ←→Select Screen
Enter Select ▶ SubMenu
F10 Save and Exit
System Time and System Date
The hour is displayed with 24-hour format. The values set in these two fields take
effect immediately.
Processor Type
