Compaq 5000 Series Replacing

36 R
EPLACING THE
S
YSTEM
B
OARD
VII. Replacing the Graphics Card
To replace the graphics card, complete the following
procedure:
1. Align the graphics card with the AGP slot 1 on the system
board. Insert the card carefully and firmly into the AGP
slot (see Figure 7-1).
2. Replace the screw 2 to secure the graphics card to the
chassis (see Figure 7-1).
Figure 7-1

Compaq 5000 Series Specifications

General

Memory Type	SDRAM
Optical Drive	CD-ROM or DVD-ROM
Audio	Integrated
Operating System	Windows 98
Ports	USB, Serial, Parallel, PS/2
Expansion Slots	PCI
