Compaq Evo N800c Series

5–46 Maintenance and Service Guide
Removal and Replacement Procedures
✎
A plastic fan channel 1 attaches to the right display support.
The channel has two slots 2 on either end that fit around two
tabs 3 on the display support. The fan channel is included in
the Miscellaneous Plastics/Hardware Kit, spare part numbers
285261-001 and 286868-001 (Figure 5-33).
Figure 5-33. Replacing the Fan Channel on the Right
Display Support
