- 1 -
ENGLISH
Size 55cm/22"(51cm/20" Diagonal Viewable Image)
Mask type Aperture grille
Gun In-line
Deflection angle 90°
CRT Phosphors Red, Green, Blue EBU (medium short persistence)
Aperture grille pitch 0.24mm
Phosphor pitch 0.25mm
Face Plate Anti-glare, Anti-reflection and Anti-static coating
Focusing method Dynamic Beam Forming (DBF)
Video 0.7Vp-p analog RGB
Sync Separate H, V sync.
Input Connectors DB9-15P x 2
Input Impedance 75 Ω (video), 2.2k Ω (sync.)
SCANNING Horizontal 30 - 121kHz
FREQUENCY Vertical 50 - 160Hz
RESOLUTION (HxV) 2048 dots x 1536 lines Non-Interlaced maximum addressable resolution format at 75Hz
WARM-UP TIME 30 minutes to reach optimum performance level
BRIGHTNESS 100cd/m
2
, standard full white video signal at 9300K (+ 8MPCD)
AC100-120/220-240V±10% 50/60Hz 140W (typ.) < 155w (typ.) with USB operation>
BLANKING TIME Horizontal > 2.3 µsec (typ.)
Vertical > 450 µsec (typ.)
DISPLAY SIZE 393mm x 295mm(typ.) ratio 4:3
COLOR 5000K~9300K
OPERATING Temperature 10- 35°C
ENVIRONMENT Humidity 20 - 80%RH (without condensation)
DIMENSIONS (W)19.7inch x (H)19.7inch x (D)19.0inch / (W) 500mm x (H) 500mm x (D) 482mm
WEIGHT Approx. 30kg (66.14 lbs.)
TILT/SWIVEL Tilt Angle -5° - +10°
BASE Swivel Angle ±90°
Safety UL1950 (UL), CSA C22.2 No.950 (C-UL)
EN60950 (TÜV-GS), NEMKO, SEMKO, DEMKO, FIMKO
EMC FCC Class-B, DOC Class-B
EN55022 Class-B, VCCI Class-B
EN50082-1, EN61000-3-2, EN61000-3-3
REGULATIONS X-Ray DHHS, HWC, Röv vom 8.1, 1987
Other CE-Marking, MPR-II/TCO'91
ISO9241-3, ISO9241-7, ISO9241-8 (TÜV-GS)
TCO '99
International E
NERGY STAR Program
USB Functional Self-powered HUB complying with Universal Serial Bus
Specifications Rev 1.0
Interface 1 Upstream port/12 Mbps
3 Downstream ports/12 Mbps, 1.5 Mbps (500mA max. per each
downstream port)
INPUT SIGNAL
SIGNAL INTERFACE
POWER SOURCE
22" Model
6 SPECIFICATIONS
