- 3 -
ENGLISH
Size 45cm/17"(41cm/16" Diagonal Viewable Image)
Mask type Aperture grille
Gun In-line
Deflection angle 90°
CRT Phosphors Red, Green, Blue EBU (medium short persistence)
Aperture grille pitch 0.25mm
Face Plate Anti-glare, Anti-reflection and Anti-static film
Focusing method Dynamic Beam Forming (DBF)
Video 0.7Vp-p analog RGB
Sync Separated H, V sync. or Composite sync
Input Connector DB9 - 15P
Input Impedance 75 Ω (video), 2.2k Ω (sync.)
SCANNING Horizontal 30 - 96kHz
FREQUENCY Vertical 50 - 130Hz
RESOLUTION (HxV) 1600dots x 1200lines Non-Interlaced maximum addressable resolution format at 75Hz
Recommended Resolution: 1024 dots x 768 lines at 85Hz
WARM-UP TIME 30 minutes to reach optimum performance level
BRIGHTNESS 110cd/m
2
, standard full white video signal at 9300K (+ 27MPCD)
BLANKING TIME Horizontal > or = 2.7µsec (typ.)
Vertical > or = 500 µsec (typ.)
DISPLAY SIZE 312mm x 234mm(typ.) ratio 4:3
COLOR TEMPERATURE
5000K~9300K
AC100-120/220-240V±10% 50/60Hz 95W (typ.) (AC 220-240V + or - 10% 50 Hz for Europe)
OPERATING Temperature 10 - 35°C
ENVIRONMENT Humidity 20 - 80%RH (without condensation)
DIMENSIONS (W)16.1inch x (H)16.2inch x (D)17.1inch / (W) 410.2mm x (H) 412.6mm x (D) 435.3mm
WEIGHT Approx. 17.5 kg (38.6 lbs.)
TILT/SWIVEL Tilt Angle -5° - +15°
BASE Swivel Angle ±90°
Safety UL1950 (UL), CSA C22.2 No.950 (C-UL)
EN60950 (TÜV-GS), NEMKO, SEMKO, DEMKO, FIMKO
EMC FCC Class-B, DOC Class-B
EN55022 Class-B
EN50082-1, EN60555-2, EN61000-3-3
REGULATIONS X-Ray DHHS, HWC, Röv vom 8.1, 1987
Other CE-Marking, MPR-II/TCO'91
TCO '99, ISO9241-3,-7, and -8 (TÜV-GS)
International ENERGY STAR Program
17" Model
INPUT SIGNAL
SIGNAL INTERFACE
