Compaq P900 - Page 19

— 31 —
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
Note:
Les composants identifies per un trame et une marque
sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
P900
Note:
The components identified by shading
and mark
are critical for safety. Replace
only with part number specified.
C123 1-104-341-11 MYLAR 0.1µF 10% 250V
C130 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C152 1-126-933-11 ELECT 100µF 20% 16V
C204 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C205 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C206 1-117-450-11 MYLAR 0.47µF 10% 250V
C208 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C211 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C212 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C220 1-126-933-11 ELECT 100µF 20% 16V
C221 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C222 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C223 1-104-341-11 MYLAR 0.1µF 10% 250V
C230 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C252 1-126-933-11 ELECT 100µF 20% 16V
C304 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C305 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C306 1-117-450-11 MYLAR 0.47µF 10% 250V
C308 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C311 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C312 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C319 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C320 1-126-933-11 ELECT 100µF 20% 16V
C321 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C322 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C323 1-104-341-11 MYLAR 0.1µF 10% 250V
C330 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C352 1-126-933-11 ELECT 100µF 20% 16V
CONNECTOR
CN301 1-764-101-11 PIN, CONNECTOR (PC BOARD) 2P
CN302 1-695-915-11 TAB (CONTACT)
CN303 1-695-915-11 TAB (CONTACT)
CN305 * 1-564-522-11 PLUG, CONNECTOR 7P
CN306 * 1-564-511-11 PLUG, CONNECTOR 8P
CN307 1-793-183-11 CONNECTOR, D SUB 15P
CN309 * 1-564-511-11 PLUG, CONNECTOR 8P
CN308 1-695-915-11 TAB (CONTACT)
CN310 * 1-779-944-21 PIN, CONNECTOR (PC BOARD) 4P
CN311 * 1-564-507-11 PLUG, CONNECTOR 4P
DIODE
D002 8-719-070-11 DIODE NNCD5.6A-T1
D004 8-719-070-11 DIODE NNCD5.6A-T1
D005 8-719-062-51 DIODE 1PS226-115
D007 8-719-109-89 DIODE RD5.6ESB2
D008 8-719-109-89 DIODE RD5.6ESB2
D010 8-719-109-89 DIODE RD5.6ESB2
D011 8-719-109-89 DIODE RD5.6ESB2
D012 8-719-062-51 DIODE 1PS226-115
D014 8-719-911-19 DIODE 1SS119-25
D016 8-719-070-11 DIODE NNCD5.6A-T1
D019 8-719-070-11 DIODE NNCD5.6A-T1
D023 8-719-921-54 DIODE MTZJ-6.2B
D024 8-719-921-54 DIODE MTZJ-6.2B
D025 8-719-921-54 DIODE MTZJ-6.2B
D026 8-719-911-19 DIODE 1SS119-25
D101 8-719-062-51 DIODE 1PS226-115
D104 8-719-052-12 DIODE HSU83TRF
D105 8-719-052-12 DIODE HSU83TRF
D106 8-719-052-12 DIODE HSU83TRF
D108 8-719-062-51 DIODE 1PS226-115
D109 8-719-052-12 DIODE HSU83TRF
D111 8-719-062-51 DIODE 1PS226-115
D201 8-719-062-51 DIODE 1PS226-115
D204 8-719-052-12 DIODE HSU83TRF
D205 8-719-052-12 DIODE HSU83TRF
D206 8-719-052-12 DIODE HSU83TRF
D208 8-719-062-51 DIODE 1PS226-115
D209 8-719-052-12 DIODE HSU83TRF
D211 8-719-062-51 DIODE 1PS226-115
D301 8-719-062-51 DIODE 1PS226-115
D304 8-719-052-12 DIODE HSU83TRF
D305 8-719-052-12 DIODE HSU83TRF
D306 8-719-052-12 DIODE HSU83TRF
D308 8-719-062-51 DIODE 1PS226-115
D309 8-719-052-12 DIODE HSU83TRF
D311 8-719-062-51 DIODE 1PS226-115
D409 8-719-052-12 DIODE HSU83TRF
FERRITE BEAD
FB001 1-412-911-11 FERRITE 0µH
FB002 1-412-911-11 FERRITE 0µH
FB004 1-412-911-11 FERRITE 0µH
FB005 1-412-911-11 FERRITE 0µH
FB009 1-414-231-22 INDUCTOR CHIP 0µH
FB010 1-414-231-22 INDUCTOR CHIP 0µH
FB012 1-414-231-22 INDUCTOR CHIP 0µH
FB014 1-216-295-91 SHORT
FB015 1-414-231-22 INDUCTOR CHIP 0µH
FB016 1-414-231-22 INDUCTOR CHIP 0µH
FB017 1-414-231-22 INDUCTOR CHIP 0µH
FB018 1-414-231-22 INDUCTOR CHIP 0µH
FB019 1-414-231-22 INDUCTOR CHIP 0µH
FB020 1-414-231-22 INDUCTOR CHIP 0µH
FB021 1-414-231-22 INDUCTOR CHIP 0µH
FB022 1-216-295-91 SHORT
A
