— 30 —
P900
RESISTORS
• All resistors are in ohms
• F : nonflammable
• The components identified by in this
manual have been carefully factory-selected
for each set in order to satisfy regulations
regarding X-ray radiation. Should
replacement be required, replace only with
the value originally used.
• Items marked * are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
When indicating parts by reference
number, please include the board name.
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
are critical for safety. Replace
only with part number specified.
Note:
Note:
Les composants identifies per un trame et
une marque
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
A
SECTION 6
ELECTRICAL PARTS LIST
* A-1299-063-A A BOARD, COMPLETE
4-382-854-01 SCREW (M3X8), P, SW (+)
CAPACITOR
C001 1-162-318-11 CERAMIC 0.001µF 10% 500V
C002 1-162-318-11 CERAMIC 0.001µF 10% 500V
C003 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C007 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C009 1-126-964-11 ELECT 10µF 20% 50V
C010 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C011 1-106-220-00 MYLAR 0.1µF 10% 100V
C012 1-164-004-11 CERAMIC 0.1µF 10% 25V
C013 1-107-888-11 ELECT 47µF 20% 25V
C014 1-107-932-11 ELECT 47µF 20% 100V
C015 1-164-004-11 CERAMIC 0.1µF 10% 25V
C016 1-126-935-11 ELECT 470µF 20% 16V
C018 1-107-652-11 ELECT 10µF 20% 250V
C019 1-163-021-91 CERAMIC 0.01µF 10% 50V
C020 1-126-935-11 ELECT 470µF 20% 16V
C021 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C022 1-126-934-11 ELECT 220µF 20% 10V
C027 1-163-021-91 CERAMIC 0.01µF 10% 50V
C028 1-104-664-11 ELECT 47µF 20% 25V
C029 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C031 1-162-318-11 CERAMIC 0.001µF 10% 500V
C032 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C033 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C035 1-162-134-11 CERAMIC 470PF 10% 2KV
C037 1-137-198-81 MYLAR 1µF 5% 50V
C038 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C039 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C040 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C041 1-162-318-11 CERAMIC 0.001µF 10% 500V
C042 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C043 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C045 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C046 1-164-346-11 CERAMIC CHIP 1µF 16V
C047 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C048 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C049 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C053 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C054 1-104-341-11 MYLAR 0.1µF 10% 250V
C056 1-163-259-91 CERAMIC 220PF 5% 50V
C059 1-164-346-11 CERAMIC CHIP 1µF 16V
C060 1-104-664-11 ELECT 47µF 20% 25V
C061 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C063 1-126-964-11 ELECT 10µF 20% 50V
C064 1-104-664-11 ELECT 47µF 20% 25V
C065 1-104-664-11 ELECT 47µF 20% 25V
C066 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C067 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C068 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C069 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C070 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C090 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C092 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C093 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C094 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C095 1-126-935-11 ELECT 470µF 20% 16V
C096 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C097 1-102-525-11 CERAMIC 68PF 5% 50V
C102 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V
C104 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C105 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C106 1-117-450-11 MYLAR 0.47µF 10% 250V
C108 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C109 1-104-664-11 ELECT 47µF 20% 25V
C111 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C112 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C119 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C120 1-126-933-11 ELECT 100µF 20% 16V
C121 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C122 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
To Next Page
