— 34 —
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
Note: Note:
Les composants identifies per un trame et une marque
sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
The components identified by shading
and mark
are critical for safety. Replace
only with part number specified.
P900
R311 1-249-403-11 CARBON 68 5% 1/4W F
R315 1-216-107-00 RES,CHIP 270K 5% 1/10W
R317 1-216-019-00 RES,CHIP 56 5% 1/10W
R318 1-216-013-00 RES,CHIP 33 5% 1/10W
R319 1-216-113-00 RES,CHIP 470K 5% 1/10W
R320 1-216-113-00 RES,CHIP 470K 5% 1/10W
R322 1-216-113-00 RES,CHIP 470K 5% 1/10W
R323 1-216-037-00 RES,CHIP 330 5% 1/10W
R330 1-216-019-00 RES,CHIP 56 5% 1/10W
R333 1-216-019-00 RES,CHIP 56 5% 1/10W
R340 1-216-019-00 RES,CHIP 56 5% 1/10W
R351 1-219-742-11 CARBON 47 5% 1/2W
R361 1-215-395-00 METAL 82 1% 1/4W
SPARK GAP
SG001 1-519-422-11 GAP, SPARK
SG002 1-519-421-11 GAP, DISCHARGE
SG101 1-519-421-11 GAP, DISCHARGE
SG201 1-519-421-11 GAP, DISCHARGE
SG301 1-519-421-11 GAP, DISCHARGE
CRYSTAL
X001 1-781-472-21 VIBRATOR, CERAMIC
D
* A-1346-862-B D BOARD, COMPLETE
1-533-223-11 CLIP, FUSE
4-061-192-11 SHEET, INSULATE
4-382-854-01 SCREW (M3X8), P, SW (+)
4-382-854-11 SCREW (M3X10), P, SW (+)
4-382-854-21 SCREW (M3X14), P, SW (+)
CAPACITOR
C401 1-128-730-91 ELECT 470µF 20% 25V
C402 1-106-228-00 MYLAR 0.22µF 10% 100V
C403 1-128-749-91 ELECT 220µF 20% 50V
C404 1-128-730-91 ELECT 470µF 20% 25V
C406 1-137-366-11 MYLAR 0.0022µF 5% 50V
C407 1-164-182-11 CERAMIC CHIP 0.0033µF 10% 50V
C409 1-126-968-11 ELECT 100µF 20% 50V
C500 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C501 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C503 1-137-370-11 MYLAR 0.01µF 5% 50V
C504 1-137-368-11 MYLAR 0.0047µF 5% 50V
C505 1-128-729-91 ELECT 330µF 20% 25V
C506 1-127-810-51 ELECT MELF 22µF 20% 250V
C507 1-136-187-11 MYLAR 0.047µF 10% 250V
C508 1-117-959-11 FILM 4700PF 3% 1.8KV
C509 1-107-444-11 CERAMIC 100PF 5% 2KV
C510 1-136-684-51 MYLAR 0.0022µF 10% 100V
C511 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C512 1-102-114-00 CERAMIC 470PF 10% 50V
C513 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C514 1-137-368-11 MYLAR 0.0047µF 5% 50V
C515 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C516 1-126-382-11 ELECT 100µF 20% 16V
C517 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C518 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C520 1-163-024-00 CERAMIC CHIP 0.018µF 10% 50V
C521 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C522 1-126-965-11 ELECT 22µF 20% 50V
C523 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C524 1-126-382-11 ELECT 100µF 20% 16V
C525 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C527 1-163-019-00 CERAMIC CHIP 0.0068µF 10% 50V
C528 1-130-489-00 MYLAR 0.033µF 5% 50V
C529 1-137-370-11 MYLAR 0.01µF 5% 50V
C530 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C531 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C532 1-107-906-11 ELECT 10µF 20% 50V
C533 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C534 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C535 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C536 1-107-665-11 ELECT 0.47µF 20% 400V
C537 1-107-770-11 FILM 0.16µF 3% 400V
C538 1-107-651-11 ELECT 4.7µF 20% 250V
C539 1-117-673-11 FILM 1.5µF 5% 250V
C540 1-107-888-11 ELECT 47µF 20% 25V
C541 1-109-844-11 FILM 0.68µF 5% 250V
C542 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C543 1-117-665-11 FILM 0.33µF 5% 250V
C544 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C545 1-117-661-21 FILM 0.15µF 5% 250V
C546 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C547 1-119-860-11 FILM 0.082µF 5% 250V
C548 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C549 1-117-953-91 FILM 0.033µF 5% 400V
C550 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C551 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C553 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C554 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C555 1-137-194-81 MYLAR 0.47µF 5% 50V
C556 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C557 1-126-935-11 ELECT 470µF 20% 16V
A
D
