— 38 —
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
Note: Note:
Les composants identifies per un trame et une marque
sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
The components identified by shading
and mark
are critical for safety. Replace
only with part number specified.
P900
JR032 1-216-296-91 SHORT
JR033 1-216-296-91 SHORT
JR034 1-216-296-91 SHORT
JR035 1-216-296-91 SHORT
JR036 1-216-295-91 SHORT
JR037 1-216-296-91 SHORT
JR038 1-216-296-91 SHORT
JR039 1-216-296-91 SHORT
JR040 1-216-295-91 SHORT
JR042 1-216-296-91 SHORT
JR046 1-216-296-91 SHORT
JR050 1-216-295-91 SHORT
JR051 1-216-296-91 SHORT
JR052 1-216-296-91 SHORT
JR602 1-216-295-91 SHORT
JR603 1-216-295-91 SHORT
JR604 1-216-295-91 SHORT
JR606 1-216-295-91 SHORT
COIL
L501 1-412-541-21 INDUCTOR 220µH
L502 1-419-299-11 COIL, HORIZONTAL LINEARITY
L503 1-419-298-11 COIL, HORIZONTAL CENTER
L504 1-406-675-11 INDUCTOR 4.7mH
L505 1-406-675-11 INDUCTOR 4.7mH
L506 1-406-675-11 INDUCTOR 4.7mH
L507 1-412-537-31 INDUCTOR 100µH
L603 1-412-537-31 INDUCTOR 100µH
L604 1-406-665-11 INDUCTOR 100µH
L606 1-406-665-11 INDUCTOR 100µH
L607 1-414-158-11 INDUCTOR 2.2µH
L608 1-414-488-21 INDUCTOR 1µH
L901 1-412-537-31 INDUCTOR 100µH
L902 1-406-659-11 INDUCTOR 10µH
FILTER
LF602 1-429-180-11 TRANSFORMER, LINE FILTER
TRANSISTOR
Q501 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q502 8-729-901-87 TRANSISTOR 2SC2411K-CQ
Q503 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
Q504 8-729-042-34 TRANSISTOR IRFU110A
Q505 8-729-050-12 TRANSISTOR 2SC5445(LBSONY1)
Q506 8-729-043-63 TRANSISTOR IRFI9634G-LF35
Q507 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q508 8-729-901-87 TRANSISTOR 2SC2411K-CQ
Q509 8-729-901-97 TRANSISTOR 2SA1036K-Q
Q510 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q511 8-729-043-41 TRANSISTOR 2SK2089-01MR-F119
Q512 8-729-043-41 TRANSISTOR 2SK2089-01MR-F119
Q513 8-729-043-41 TRANSISTOR 2SK2089-01MR-F119
Q514 8-729-047-72 TRANSISTOR 2SK3155-01
Q515 8-729-047-72 TRANSISTOR 2SK3155-01
Q516 8-729-047-72 TRANSISTOR 2SK3155-01
Q517 8-729-140-50 TRANSISTOR 2SC3209LK
Q519 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q605 8-729-050-14 TRANSISTOR 2SK3265LB2SONY
Q606 8-729-043-27 TRANSISTOR PDTC114EK-115
Q607 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q608 8-729-029-92 TRANSISTOR DTC143ESA
Q609 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q701 8-729-800-32 TRANSISTOR 2SC2362K-G
Q702 8-729-178-43 TRANSISTOR 2SC2784-E
Q703 8-729-204-91 TRANSISTOR 2SA1049-GR
Q704 8-729-207-82 TRANSISTOR 2SC3421-Y
Q705 8-729-207-89 TRANSISTOR 2SA1358-Y
Q706 8-729-031-89 TRANSISTOR 2SC3941A-Q(TA)
Q901 8-729-043-63 TRANSISTOR IRFI9634G-LF35
Q902 8-729-041-45 TRANSISTOR FS5KM-16A
Q903 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q904 8-729-901-97 TRANSISTOR 2SA1036K-Q
RESISTOR
R401 1-249-383-11 CARBON 1.5 5% 1/4W F
R402 1-215-866-11 METAL OXIDE 330 5% 1W F
R403 1-214-796-00 METAL 1.5 1% 1/2W
R404 1-215-449-00 METAL 15K 1% 1/4W
R405 1-214-796-00 METAL 1.5 1% 1/2W
R406 1-216-663-11 METAL CHIP 3.3K 0.50% 1/10W
R407 1-249-397-11 CARBON 22 5% 1/4W F
R409 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R410 1-216-663-11 METAL CHIP 3.3K 0.50% 1/10W
R416 1-216-073-00 RES,CHIP 10K 5% 1/10W
R417 1-216-113-00 RES,CHIP 470K 5% 1/10W
R418 1-216-105-91 RES,CHIP 220K 5% 1/10W
R501 1-216-049-91 RES,CHIP 1K 5% 1/10W
R502 1-216-025-91 RES,CHIP 100 5% 1/10W
R503 1-216-033-00 RES,CHIP 220 5% 1/10W
R504 1-216-073-00 RES,CHIP 10K 5% 1/10W
R505 1-216-081-00 RES,CHIP 22K 5% 1/10W
R506 1-247-807-31 CARBON 100 5% 1/4W
R507 1-247-863-91 CARBON 22K 5% 1/4W
R508 1-215-861-00 METAL OXIDE 47 5% 1W F
R509 1-249-381-11 CARBON 1 5% 1/4W F
R510 1-219-677-11 METAL 1.8 5% 10W
D
