REMOVAL & REPLACEMENT
Mass Storage Devices
Removing the Hard Drive, continued
Removal
5
Lift up the hard drive bracket,
disconnect the (1) power and
(2) data cable from the hard
drive, and remove the hard
drive bracket with the hard
drive attached from the
chassis.
Removing the Hard Drive
Bracket
