REMOVAL & REPLACEMENT
Mass Storage Devices
Removing the Hard Drive Bracket
Removal
Remove (1) two screws from
each side of the drive bracket.
Lift the (2) hard drive from the
bracket.
To replace the hard drive and
bracket reverse the previous
procedure.
