Maintenance and Service Guide
Compaq Presario EZ2000 Series Computers
Product Description Troubleshooting Illustrated Parts Catalog
Home Removal & Replacement Jumper & Switch Information Specifications
3.5" Diskette
Drive
Hard Drive
CD or DVD and
CD-RW Drive
Mass storage
devices index
page
REMOVAL & REPLACEMENT
Removing the Mass Storage Devices
Removing the Diskette Drive
To remove the diskette drive,
complete the following steps:
Removal
1
Perform preparation
procedures.
2
Remove the Left Easy Access
panel.
3
Remove the drive cage.
4
Disconnect the diskette drive
data cable from the system
board.
NEXT STEP
