Compaq Presario CQ40-400 - Notebook PC - Modem) (Select Models Only); Network)

RJ-11 (modem) (select models only)
Pin Signal
1 Unused
2 Tip
3 Ring
4 Unused
5 Unused
6Unused
RJ-45 (network)
Pin Signal
1 Transmit +
2 Transmit -
3 Receive +
4 Unused
5 Unused
6 Receive -
7 Unused
8Unused
128 Chapter 9 Connector pin assignments
