Compaq TFT1720 User Manual

English 9
Setting Up the Monitor
Connecting the cables to the monitor
Look at the following diagram and follow the steps listed below to
connect the cables to the monitor.
CAUTION: This monitor is equipped with an auto-sensing power
supply for voltage ranges 100—240 V AC, 50/60
Hz. Use the monitor with the supplied DC adapter
only.
a
b
K
a - b ≥ 300 mm

Compaq TFT1720 Specifications

General

Brand	Compaq
Model	TFT1720
Category	Monitor
Language	English
