User Modes
The video controller signal may occasionally call for a mode that is not
preset if:
n You are not using a Compaq standard graphics adapter.
n You are not using a preset mode.
If this occurs, you may need to readjust the parameters of the monitor
screen by using the on-screen display. User changes can be made to any
or all of these modes and saved in memory. The monitor automatically
stores the new setting, then automatically recognizes the new mode just
as it does a preset mode. In addition to the 22 preset modes that can be
changed and stored, there are 14 user modes that can be entered and
stored.
To revert back to the factory default settings, select Reset from the
Factory Reset menu in the on-screen display, and the factory default
resolutions will replace the user changes made for the operating original
display mode.
Energy Saver Feature
The energy saver feature has three different modes of operation:
n Full power
n Suspend
n Sleep
By selecting settings in the computer's Energy Saver utility, you are able
to determine the length of inactivity before the monitor goes into suspend
or sleep mode.
The following table describes the monitor energy saver levels available
during the different modes of operation.
Energy Saver Levels
Mode Power Usage Description
Full
Power
Less than
160 watts
ON = Normal operation
Power LED is green.
Suspend Less than
15 watts
Monitor screen is blanked. Power LED turns yellow. Full
power mode returns quickly.
Sleep Less than
5 watts
Monitor screen is blanked. Power LED turns amber. There is
a brief warm-up period before returning to full power mode.
Refer to your computer manual for instructions on setting energy saver
features (sometimes referred to as power management features).
