General information
941210 Battery unit
Nickel metal hybrid (NiMH) rechargeable
(4.8V / ≥ 1,200 mA/h).
68301x Chargers
Only battery chargers bearing the following
information can be used to recharge
the batteries supplied with Compex
stimulators:
Europe
683010
Type TR1509-06-E-133A03
Input 100-240 VAC / 47-63 Hz / 0.5 A max.
Output 9 V / 1.4 A / 15 W
UK
683012
Type TR1509-06-U-133A03
Input 100-240 VAC / 47-63 Hz / 0.5 A max.
Output 9 V / 1.4 A / 15 W
601131 Black Snap-connection
stimulation cables
Device connector: 6-pin
Electrode connector: Female Snap
Length: 1,500 mm
601160 Stimulation cable tted
with
m i-SENSOR
(accessory sold separately)
Device connector: 6-pin
Electrode connector: Female Snap
Length: 1,500 mm
The On/O button is a multifunction
button (symbol no. 5009 IEC 60878).
Functions
On/O (two stable positions)
Waiting or preparation for part of the unit
Stop (turns system o)
 Technical characteristics
Protection index
IPXO (IEC 60529)
Neuro-stimulation
All electrical specications are given for an
impedance of 500-1,000 ohms per channel.
Channels: Four independent and individually
adjustable channels that are electrically
isolated from each other and earthed.
Pulse shape: constant rectangular current
with pulse compensation to eliminate
any direct current component to prevent
residual polarisation at skin level.
Maximum pulse intensity: 120 mA.
Pulse intensity increments: manual
adjustment of stimulation intensity from 0
to 999 (energy) in minimum increments of
0.5 mA.
Pulse width: 60 to 400 s.
Maximum electrical charge per pulse:
96 microcoulombs (2 x 48 C,
compensated).
Standard pulse ramp-up time: 3 s (20%
80% of maximum current).
Pulse frequency: 1 to 150 Hz.
