RECHARGING THE DEVICE
Never recharge the stimulator without first
disconnecting the lead wires.
The Compex® Wired 3.0 has considerable operating
autonomy, as it uses a rechargeable battery.
The battery’s life depends on the programs and
stimulation energy used.
There are two ways to recharge the battery with a
USB charging cable which has a micro connector
and is supplied with the device. The device may be
charged by connecting to a USB port on a PC or
by a power supply adapter approved by DJO (see
Specifications section). Push aside the rubber cover
of silicone sleeve which locates at the left side near
bottom and there is a USB socket. Plug one end of
USB charging cable into this socket and another end
connecting to PC or adapter as below picture shows:
We strongly recommend you fully charge the battery before using it for the first time as this
will improve its autonomy and life span. If you do not use your device for a long period of time,
please recharge the battery regularly.
If the battery icon shows only one bar of power left, this means
that power is running low. Stop the session and recharge the unit.
If the battery icon shows only one red bar of power left, this
means that the battery is completely discharged. It is no longer
possible to use the device. Recharge it immediately.
The charge state of the battery is indicated by a small battery icon on the top right screen.
A: BATTERY LEVEL
Before charging:
Remove all lead wires from the stimulator before recharging it.
Charging by adapter:
Connect the charger to the mains and then connect the stimulator to the charger. The charge
menu shown below will automatically appears on the screen.
Charging by PC:
Connect the stimulator to the PC with the USB charging cable. The charging and fully charged
menu are the same as charging by adapter.
After Charging:
When battery is fully charged, simply disconnect the charger or PC-and the Compex® Compex®
Wired 3.0 will turn on automatically.
The big battery icon is animated while the battery is recharging. When fully charged, this icon will
be full of green and the battery bar on top right of screen will be also full, refer to below picture.
B: RECHARGING
Note: Programs may vary depending on device
DEVICE PROGRAMS
Program Names
Strength Potentiation
Endurance Training Recovery
Resistance Competition Recovery
Explosive Strength Prewarm-up
Muscle Relaxation Pain Relief Tens
Program name Sport Elite Performance Edge
Strength
Endurance
Resistance
Explosive Strength
Muscle Relaxation
Potentiation
Training Recovery
Competition Recovery
Prewarm-up
Pain Relief Tens
DEVICE PROGRAM COMPARISON CHART
Wired 3.0
