● Carefully ensure the conduit is located in the slot in the side of the battery box and the wires to
the contact springs pass through the small channel. Re-attach the battery box to the seat again.
● Re-connect the 12V power supply and test the installation by pinching the springs together to
observe the liquid light turning on.
Get outta here - Configuring CUDDY™ to Vent Externally
When he arrives, CUDDY is configured to recirculate air through the carbon filter to reduce odors. CUDDY
can be configured to vent externally if desired.
Tools Required:
Philips Screwdriver
Flat Screwdriver
Additional materials required (not supplied):
Ventilation hose (0.825”/21mm Internal Diameter )
Jubilee clip to secure the hose
Fly screen or similar gause
Victory Beverage
● Disconnect the power supply at the rear.
● Remove CUDDY’s solids bin and Carbon Filter.
● Unscrew the filter adapter as shown.
● Using the flat head screwdriver, remove the circulation adapter between the four plastic bosses.
● Invert the circulation adapter and secure it by replacing the filter adapter as shown below.
