Air will now vent externally from the unit through the exhaust pipe.
We recommend placing a fly mesh over the vent outlet before securing the vent hose using a jubilee clip.
The vent hose can then be vented externally through the floor, wall, or ceiling when using an appropriate
cowling.
● Replace the solids bin and reconnect the power.
● Confirm air is flowing through the external vent as expected by testing flow from the outlet with
your hand.
● Wash your hands and enjoy victory beverage.
Shore-can! - Configuring CUDDY™ with mains power
Tools Required:
None
Additional Materials Required (not included):
5.5mm x 2.1mm 12V 1A power adapter.
Victory Beverage
● CUDDY takes power for the fan via a 5.5 x 2.1mm DC power supply. These are commonly available
worldwide for all domestic power supplies.
● To connect CUDDY to mains power, obtain an appropriate 5.5 x 2.1mm 12V adapter for your
domestic power supply in either 1A or 2A power rating.
