compupool products CPSC Series - Installation Wiring (Continued); Internal Transformer Wiring Diagrams

Compu Pool CPSC Series Manual 11
7.3.8 Figure 1 - Internal Transformer Connections - 120 VAC Connections.
7.3.9 Figure 2 - Internal Transformer Connections - 240VAC Connections.
Black Wire
Orange Wire
Red Wire
Brown Wire
Black Wire
Orange Wire
Red Wire
Brown Wire
120 VAC
Connections
240 VAC
Connections
