7. Slide and insert the ribbon guide between the print head and the ribbon guide mask holding it
perpendicular to the print head.
Make sure that the ribbon is inserted correctly between the print head and the print head mask.
OK
NO
8. If the shifter kit option is installed on
your printer, insert the shifter holder
onto the ribbon shifter as shown in
this figure.
Shifter Holde
To Next Page
