51
A Passbook width 241 mm 110 mm
B Passbook length 220 mm 85 mm
C Distance for the dot
position nearest to the left
or right edge
- 3,0 mm
D Distance from the top
edge of the document to
the top edge of the first
printed line
- 1 mm
E Distance from the bottom
of the last printed line to
the bottom edge of the
document
- 6,6 mm
F Outer corner radius 9,35 mm -
G Distance from the fold to
the first character
position beside the fold.
- 6,87 mm
H Distance from the fold to
the first character
position beside the fold.
- 6,87 mm
K-L Short Page Offset - 0,0 mm
Book thickness, while
open
1,8 mm 0,28 mm
