CONDOR 500 - schema di collegamento dei motori
• DELAY LED OFF = DELAY OF THE MOTOR n.2
• DELAY LED ON = DELAY OF THE MOTOR n.1
Conguration - MASTER ON THE RIGHT, SLAVE ON THE LEFT
2N D
CN1
CN5
F1
L24 L24 M1+ M1 M2+ M2
1
1
2
2
MOTOR n.1 (on the left)
24V with M1+
0V with M1-
MOTOR n.2 (on the right)
24V with M2-
0V with M2+
