COMUNELLO ®Copyright 2014 - All right reserved
3. CODE TX: (Remote control code)
Up to 120 remotes with different codes of either the xed or the rolling code
type can be saved on the control unit.
Programming:
Programming of the transmission code is performed as follows: use the
SELECT key to select blinking LED L3. Press SET once; the LED will change
its blinking mode (longer 1 0 1 0) to show that the rst level is being saved.
On sending the selected code with the desired remote, the CODE LED will
remain steady on to indicate that programming has been completed.
To save the code for pedestrian opening / single leaf proceed as follows: use
the SELECT key to select blinking LED L3. Press SET twice consecutively;
the LED will change its blinking mode (1 1 0 1 1 0) to show that the
pedestrian code is being saved. On sending the selected code with the
desired remote LED L3 will remain steady on to indicate that programming
has been completed.
If all 120 codes have been saved, repeating the programming operation will
cause all the programming LEDs to start blinking to signal that no further
codes can be saved.
Deletion:
Use SELECT to go to LED L3; activate blinking of the code to be deleted
(CODE or PEDESTRIAN identied by the respective blinking); press and
hold down SET for > 5 s. After this interval the LED will switch off for 2
seconds and the procedure is completed. If all CODE and PEDESTRIAN
codes are deleted, the LED will remain off.
If only PEDESTRIAN codes remain stored, the LED blinking mode will
change (1 1 1 1 0 1 1 1 1 0)
Rule of the rst saved Remote control:
When programming remotes the following rule is applied: if the rst remote
to be saved is of the rolling code type, the receiver will subsequently
accept only rolling code remotes, thus providing enhanced anti-intrusion
security; if the rst remote to be saved is a xed code type, the receiver will
subsequently accept both xed code remotes and rolling code remotes,
although only the xed part of the latter will be controlled (thus effectively
relinquishing the security of the rolling code system).
4. COND:
The Condominium function means that during the opening movement or
during the pause time the control unit will not respond to commands sent
by Pushbuttons or remotes. In contrast, during the closing movement a
command sent by the Pushbuttons or the remotes will reverse the direction
of movement. This operating mode is invaluable when the automation
includes a loop detector.
In the default conguration the control unit is set with the Condominium
function disabled; if the Condominium function is required, proceed as
follows: use the SELECT key to select blinking LED L4 and then press the
SET key: LED L4 becomes steady on and programming will be completed.
Repeat the procedure if you wish to restore the previous conguration.
5. MOTOR TIME: (Programming of the run time of the operators with
max 4 minutes)
The control unit is factory set with a preset motor time of 30 seconds
without deceleration. If the run time of the operators must be changed,
programming must be carried out with the gate closed as follows: use
the SELECT key to select blinking LED L5 and then press the SET key
momentarily; the operator will start the opening movement; when the
desired deceleration starting point is reached, press the SET key again; at
the same time the operator will decelerate and reach the desired position;
press SET to terminate the opening cycle. Thereafter LED L5 will start
blinking rapidly; now repeat the motor time and deceleration programming
procedure for the closing cycle. If you do not require the control unit to
perform the deceleration, during programming, when the open-close cycle
has been completed press the SET key twice consecutively rather than
just once.
During programming, instead of the SET key on the control unit you can use
the button on the remote, providing the remote has been saved beforehand.
6. PAUSE TIME: (Automatic closing time programming 4 min. max.)
The control unit is factory set with automatic closing disabled. If you wish
to enable automatic closing proceed as follows: use the SELECT key to
select blinking LED L6 and press the SET key momentarily; now wait for
a time equivalent to the desired time interval; press the SET key again
momentarily and at the same time the automatic closing time will be saved
and LED L6 will remain steady on. If you wish to restore the initial condition
(no automatic closing) select blinking LED L6 and then press the SET key
twice consecutively in a time period of 2 seconds. The LED will switch off
and the operation will be completed.
During programming, instead of the SET key on the control unit you can use
the button on the remote, providing the remote has been saved beforehand.
7. AUTOMATIC PROGRAMMING:
The control unit offers the facility of Automatic Programming (SIMPLIFIED).
First bring the gate leaves to an intermediate position, use the
SELECT key to select blinking LED L7 and then hold down the SET key;
the control unit executes the Auto programming procedure by performing
a complete opening and closing cycle (keep the SET key pressed until
Auto Programming is completed). During the Auto Programming procedure
the Deceleration cycle is set automatically at approximately 15% of the
complete cycle.
During Automatic Programming, instead of the SET key on the control unit
you can use the button on the remote, providing the remote has been
saved beforehand.
EXTENDED MENU 1
The control unit is factory set to allow direct selection exclusively of the main
menu functions. If you wish to enable the functions described in Extended
Menu 1, proceed as follows: select blinking LEV LED and press SET once.
The LED will start blinking. This means there will be 30 seconds to select
the functions of Extended Menu 1 using the SELECT and SET keys; once
an additional 30 seconds have elapsed the control unit reverts to the main
menu.
1. PHOTOCELLS TEST:
The control unit is factory set with the photocells test disabled; proceed
as follows if you wish to enable the function: make sure you have enabled
extended Menu 1, use the select key to select blinking LED L1 and then
press the SET key; at the same time LED L1 will become steady on and
programming will be completed.
Repeat the procedure if you wish to restore the previous conguration.
2. PED MOT. T. (Programming of pedestrian opening motor time of
max 4 minutes):
The control unit is factory set with Motor time (Pedestrian opening) of 10
seconds without any deceleration.
If the pedestrian motor time must be changed, programming must be
carried out with the gate closed as follows: ensure you have enabled
Extended Menu 1, use the SELECT key to select blinking LED L2 and
then press the SET key momentarily. The Operator will start the Opening
cycle; when the gate reaches the desired initial deceleration position press
the SET key again: LED L2 will start blinking more slowly and the Operator
performs the deceleration; when the desired position is reached press the
SET key to terminate the Opening cycle. At this point LED L2 returns to the
normal blinking speed and the Operator restarts in the Closing movement;
repeat the operations described above for the Closing movement.
If you do not require the control unit to perform the deceleration, during
programming, when the opening and closing cycle has been completed
press the SET key twice consecutively rather than just once.
During programming, instead of the SET key on the control unit you can use
the button on the remote, providing the remote has been saved beforehand
3. DECELERATION:
As indicated above, the control unit allows a deceleration stage to be
programmed during opening and closing, while with the Automatic
Programming function the deceleration stage is included automatically.
However, if no deceleration is required, this stage can be inhibited. In this
manner, when using Automatic Programming the Deceleration stage will no
longer be included, while if the Motor Times Programming function is used
the option of specifying a deceleration stage during opening and closing
will no longer be available. If, before excluding the deceleration stage it had
already been programmed using the Motor Times Programming function,
programming must be repeated from the beginning. If the deceleration
stage is to be excluded proceed as follows: make sure you have enabled
Extended Menu 1, use the SELECT key to select blinking LED L3 and then
press the SET key: LED L3 becomes steady on and programming will be
completed. Repeat the procedure if you wish to restore the
previous conguration.
4. LEAVES DELAY (15 sec. max leaf delay programming):
L1 FOTOTEST ON OFF
L2 PEDESTRIAN TIME ON OFF
L3 DECELERATION OFF ON
L4 LEAVES DELAY ON OFF
L5 RELEASE STROKE ON OFF
L6 SLAM LOCK ON OFF
L7 COURTESY LIGHT ON OFF
LEV MENU 1 FLASH
