Comunello QUAD 24V HP - Salient System Configuration; Salient Operation Notes

7
COMUNELLO ®Copyright 2014 - All right reserved
SALIENT: DO NOT CHANGE the conguration
Opens to left, closes to right (left prole view, as in the image).
SALIENT
CN4
L24 L24 M1+ M1
M2+ M2
MOTOR 1 OUTPUT
DOESN’T CHANGE!!
RED ON + BLACK ON –
MOTOR 2 OUTPUT:
NOT USED
(NO-ELECTRICITY SUPPLIED)
1
ON
2
SW1
1
MOTOR
M2 NOT
CONSID.
