Comunello QUAD 24V HP - Abacus 2 Motor Configuration; Abacus Motor Wiring Diagram

8
COMUNELLO ®Copyright 2014 - All right reserved
2 MOTORS CONFIGURATION
ABACUS - connection diagram of the motors
1
1
2
2
CN4
L24 L24 M1+ M1
M2+ M2
• DELAY OF THE MOTOR n.2
• DELAY OF THE MOTOR n.1
Conguration:
24V with M1+
0V with M1-
24V with M2+
0V with M2-
1
ON
2
SW1
1
ON
2
SW2
2
MOTORS
INV
OFF
INV
OFF
DELAY
MOT.2
1
ON
2
SW2
1
ON
2
SW1
2
MOTORS
INV
OFF
INV
OFF
DELAY
MOT.1
