C. Upgrade procedure from the internal hard disk of the CSM3PL
1. Copying the firmware files to the CSM3PL
1.1 If you have downloaded the firmware upgrade from www.conceptronic.net, you have a ZIP file
containing a folder named ‘Firmware’ and three documentation files.
1.2 Connect the CSM3PL to your computer with the USB cable.
1.3 Copy the ‘Firmware’ folder including all its content to the hard disk of the CSM3PL.
1.4 Remove the CSM3PL from your computer with the ‘Safely remove hardware’ option.
1.5 Disconnect the USB cable of the CSM3PL and turn it off with the switch on the back side.
2. Updating the firmware
2.1 Connect the CSM3PL to a TV or monitor.
2.2 Turn on the CSM3PL with the switch on the back side.
2.3 Select the ‘Firmware’ folder by using the navigation buttons on the remote control.
A confirmation screen will be displayed asking if you want to replace the current firmware with a
new one. Choose ‘Yes’. The upgrade process will start. This is visible in the upper left corner
with the terms ‘ERASE’ and ‘WRITE’.
Note: The CSM3PL must not be turned off during the upgrade process. Doing so will
result in an unusable product which is not covered by the warranty.
2.4 As soon as the upgrade process is completed, the screen will go black.
Note: The device is still turned on. You need to manually turn off the device by pressing the
‘POWER’ button on the remote control. You can completely turn the device off by
turning off the switch on the back side of the device.
3. Removing the ‘Firmware’ folder
3.1 Connect the CSM3PL to your computer with the USB cable.
3.2 Remove the ‘Firmware’ folder from the hard disk. This makes sure the CSM3PL won’t start
updating again when the ‘Firmware’ folder is selected on your TV or monitor.
3.3 Remove the CSM3PL from your computer with the ‘Safely remove hardware’ option.
3.4 Disconnect the USB cable from the CSM3PL and turn it off with the switch on the back side.
