CONCORD ABSORBER XT - Overview

CONCORD ABSORBER XT
15 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
22
23
18
ISOFIX adapter
12
Size adjustment dial
15
Storage compartment
for user manual
13
Shoulder harness
belt guide
16
Lap harness
belt guide
14
Shoulder
harness clip
09
Harness for central
adjustment
07
Seat tilt operation
17
Control knob ISOFIX
_ OVERViEW
01 Headrest
03 Harness lock
02 Harness padding
06
Harness tensioner
08
Step-up support
10
Support leg release
11
Support leg
04
Harness clip
control knob
05 Leg support
