CONCORD ABSORBER XT - Mounting the Concord Absorber with Isofix

32
33
CaUTiOn!
• ThecarseatmustbesecuredwiththeISOFIXsystem,
even if no child is traveling in it!
• BothISOFIXadaptersmustbe
locked securely in place and the
safety displays on both adapters
must show green.
• Thesupportlegmustrest
securely on the floor and must be
locked in place.
Push the CONCORD ABSORBER backwards while
pushing down the ISOFIX control button (17) until it lies
as flush as possible along the back rest of the vehicle‘s
seat. Release the ISOFIX control button (17) once you
have the child seat in the desired position.
In vehicles with serial
headrests, a readjustment of
the headrest or its removal
will allow for a better mounting
position of the car seat.
Press the button (10) to unlock the support leg, and
move the support leg (11) downwards, until it rests
securely on the floor and you can hear and feel it lock
into position!
Please remember to readjust or replace the headrest in the correct position
if an adult will be sitting in that seat instead.
Press the ISOFIX control button (17)
at the underside of the front edge
upwards until the ISOFIX adapters
(18) at the back of the seat are fully
extended.
Set down the CONCORD ABSORBER in drive direction
onto the seat or the seat bench.
Push the child seat backwards onto the ISOFIX
receptacles until the locking mechanisms of both
ISOFIX adapters (18) audibly lock and the safety
displays on both adapters are green!
When the ISOFIX adapters has not been used for some time, they will be
locked in their current position.
To unlock the adapters, lay the CONCORD ABSORBER on its back on an
even, clean surface and push downwards on the seat area.
Fold the support leg (11) at
the bottom of the CONCORD
ABSORBER forwards until it
engages.
_ MOUnTinG THE COnCORD aBSORBER WiTH iSOFiX
