CONDTROL Auto RotoLaser
Magnetic target board
Magnetic target board helps to
make the layout of ceiling systems or
framework structures. Built-in magnet
enables attaching a target to the ceiling
rails or on the frame profile. The target
has a linear layout on its surface, which
allows determining deviation from the
nominal level and making check points
while marking by laser leveling.
ACCURACY CHECK
Axis X
1. Place the product at 0.5 m distance from one wall and 10 m
distance from another wall, so that axis X is aimed at the wall.
2. Turn on the product. As soon as self-levelling is finished, mark
location of laser line on both walls by points X1 and X2.
3. Turn off the product. Move it to the opposite wall, position of the
product should remain unchanged.
4. Turn on the product. Align laser line with the previously made
point X2. Mark point X3 on the opposite wall.
the product and contact service center.
